Planet SGS-6341-24T4X User Manual

35-203
35.27 ip ospf authentication-key
Command:
ip ospf [<ip-address>] authentication-key <LINE>
no ip ospf [<ip-address>] authentication
Function:
Specify the authentication key required in sending and receiving OSPF packet on the interface; the
“no ip ospf [<ip-address>] authentication” cancels the authentication key.
Parameter:
<ip-address> is the interface IP address shown in dotted decimal notation;
<LINE> specifies the key required in the plaintext authentication.
Default:
Authentication not required in receiving OSPF packets on the interface.
Command Mode:
Interface Configuration Mode.
Example:
Switch#config terminal
Switch(config)#interface vlan 1
Switch(Config-if-Vlan1)#ip ospf authentication-key password
35.28 ip ospf cost
Command:
ip ospf [<ip-address>] cost <cost>
no ip ospf [<ip-address>] cost
Function:
Specify the cost required in running OSPF protocol on the interface; the “no ip ospf [<ip-address>]
cost” command restores the default value.
Parameter:
<ip-address> is the interface IP address shown in dotted decimal notation.
<cost > is the cost of OSPF protocol ranging between 1~65535.
Default:
Default OSPF cost on the interface is auto-figure out based bandwidth.
Command Mode:
Interface Configuration Mode.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
