Planet SGS-6341-24T4X User Manual

14-106
14.1.13 spanning-tree hello-time
Command:
spanning-tree hello-time <time>
no spanning-tree hello-time
Function:
Set switch Hello time; The command “no spanning-tree hello-time” restores the default setting.
Parameter:
<time> is Hello time in seconds. The valid range is from 1 to 10.
Command mode:
Global Mode
Default:
Hello Time is 2 seconds by default.
Usage Guide:
Hello time is the interval that the switch sends BPDUs. Hello time is co working with forward delay
and max age. The parameters should meet the following conditions. Otherwise, the MSTP may
work incorrectly.
2 * (Bridge_Forward_Delay - 1.0 seconds) >= Bridge_Max_Age
Bridge_Max_Age >= 2 * (Bridge_Hello_Time + 1.0 seconds)
Example:
Set MSTP hello time to 5 seconds in global mode.
Switch(config)#spanning-tree hello-time 5
14.1.14 spanning-tree link-type p2p
Command:
spanning-tree link-type p2p {auto | force-true | force-false}
no spanning-tree link-type
Function:
Set the link type of the current port; the command “no spanning-tree link-type” restores link type to
auto-negotiation.
Parameter:
auto sets auto-negotiation, force-true forces the link as point-to-point type, force-false forces the
link as non point-to-point type.
Command mode:
Port Mode

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
