Planet SGS-6341-24T4X User Manual

12-67
Default:
The port is in Access mode by default.
Usage Guide:
Ports in trunk mode is called Trunk ports. Trunk ports can allow traffic of multiple VLANs to pass
through. VLAN in different switches can be interconnected with the Trunk ports. Ports under access
mode are called Access ports. An access port can be assigned to one and only one VLAN at a time.
Hybrid ports can allow traffic of multiple VLANs to pass through, receive and send the packets of
multiple VLANs, used to connect switch, or user’s computer. When Hybrid ports and Trunk ports
receive the data, the deal way is same, but the deal way is different in sending the data. Because
Hybrid ports can allow the packets of multiple VLANs to send with no tag, however, Trunk ports can
only allow the packets of the default VLAN to send with no tag. The attribute of ports can not directly
convert between Hybrid and Trunk, it must configure to be access at first, then configure to be
Hybrid or Trunk. When the Trunk or Hybrid attribute is cancelled, the port attribute restores the
default (access) attribute and belongs to vlan1.
Example:
Set port 5 to trunk mode and port 8 to access mode, port 10 to hybrid mode.
Switch(config)#interface ethernet 1/0/5
Switch(Config-If-Ethernet1/0/5)#switchport mode trunk
Switch(Config-If-Ethernet1/0/5)#exit
Switch(config)#interface ethernet 1/0/8
Switch(Config-If-Ethernet1/0/8)#switchport mode access
Switch(Config-If-Ethernet1/0/8)#exit
Switch(config)#interface ethernet 1/0/10
Switch(Config-If-Ethernet1/0/10)#switchport mode hybrid
Switch(Config-If-Ethernet1/0/10)#exit
12.1.31 switchport mode trunk allow-null
Command:
switchport mode trunk allow-null
Function:
Add a port as trunk mode. When enabling GVRP, the mode that adds the ports with trunk mode to
all VLANs is not appropriate. Therefore, add a port as trunk port and does not join any VLANs by
default for enabling GVRP on trunk port is appropriate. It is recommended to configure a port as
trunk with this command before enabling GVRP. This command can also be used when a port has
been configured as trunk already, which equals to clearing allow-list and quits all VLANs.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
