Page #590 background imageLoading...
Page #590 background image
35-229
C *> 127.0.0.0/8 is directly connected, Loopback
O 192.168.2.0/24 [110/10] is directly connected, Vlan2, 00:06:13, process 12
C *> 192.168.2.0/24 is directly connected, Vlan2
35.63 show ip protocols
Command:
show ip protocols
Function:
Display the running routing protocol messages.
Command Mode:
Admin and configuration mode
Example:
Switch#show ip protocols
Use “show ip protocols” command will show the messages of the routing protocol running on
current layer 3 switch
For example, the displayed messages are:
Routing Protocol is "ospf 0"
Invalid after 0 seconds, hold down 0, flushed after 0
Outgoing update filter list for all interfaces is
Incoming update filter list for all interfaces is
Redistributing:
Routing for Networks:
10.1.1.0/24
12.1.1.0/24
Routing Information Sources:
Gateway Distance Last Update
Distance: (default is 110)
Address Mask Distance List
Routing Protocol is "bgp 0"
Outgoing update filter list for all interfaces is
Incoming update filter list for all interfaces is
IGP synchronization is disabled
Automatic route summarization is disabled
