SGS-6341 Series Command Guide
1-54
Example:
Switch>enable
Switch#
1.1.10 enable password
Command:
enable password [0|7] <password>
no enable password
Function:
Configure the password used for enter Admin Mode from the User Mode,
The “no enable password” command deletes this password.
Parameter:
password is the password for the user. If input option 0 on password setting, the password is not encrypted; if input
option 7, the password is encrypted.
Command mode:
Global Mode
Default:
This password is empty by system default
Usage Guide:
Configure this password to prevent unauthorized entering Admin Mode. It is recommended to set the password at
the initial switch configuration. Also, it is recommended to exit Admin Mode with “exit” command when the
administrator needs to leave the terminal for a long time.
1.1.11 end
Command:
end
Function:
Quit current mode and return to Admin mode when not at User Mode/ Admin Mode.
Command mode:
Except User Mode/ Admin Mode
Example:
Quit VLAN mode and return to Admin mode.
Switch(config-vlan1)#end
Switch#

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
