Planet SGS-6341-24T4X User Manual

34-182
interface is not set
Default redistribution metric is 1
Default redistribution metric is 1
Redistributing: static Redistricting the static route into
the RIP routes
Interface
Vlan10
Vlan2
The interfaces running RIP is Vlan
10 and Vlan 2
34.23 show ipv6 rip
Command:
show ipv6 rip
Function:
Show RIPng Routing.
Command Mode:
Admin mode
Example:
Switch#show ipv6 rip
Codes: R - RIP, K - Kernel, C - Connected, S - Static, O - OSPF, I - IS-IS,
B - BGP, a - aggregate, s - suppressed
Network Next Hop If Met Tag Time
R 2000:1:1::/64 :: Vlan2 1 0
R 2001:1:1::/64 fe80::203:fff:fe01:257c Vlan2 2 0 02:40
R 3000:1:1::/64 :: Vlan10 1 0
R 3010:1:1::/64 :: -- 1 0
Amongst R stands for RIP route, namely a RIP route with the destination network address
2001:1:1::/64, next-hop address at fe80::203:fff:fe01:257c. It is learnt from the Ethernet port VLAN2
with a metric value of 2, and still has 2 minutes 40 seconds before time out.
Equal Command:
show ipv6 rip database
34.24 show ipv6 rip database
Command:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
