13-88

When VLAN interface is configured and is up, the system will generate a static address mapping

entry of which the inherent MAC address corresponds to the VLAN number.

Usage Guide:

In certain special applications or when the switch is unable to dynamically learn the MAC address,

users can use this command to manually establish mapping relation between the MAC address and

port and VLAN.

no mac-address-table command is for deleting all dynamic, static, filter MAC address entries

existing in the switch MAC address list, except application, system entries. MAC address entries can

be classified according to the different source, the types are as follows: DYNAMIC, STATIC,

APPLICATION, SYSTEM. DYNAMIC is the dynamic MAC address entries learned by switch, it can

be aged by switch automatically. STATIC is the static MAC address entries (including blackhole

entries) added by user. APPLICATION is the static MAC address entries added by application

protocol (such as dot1x, security port…). SYSTEM is the additive static MAC address entries

according to VLAN interface. When adding STATIC entries, it can cover the conflictive DYNAMIC,

except APPLICATION, SYSTEM entries.

After configure the static multicast MAC by this command, the multicast MAC traffic will be forwarded

to the specified port of the specified VLAN.

Example:

Port 1/0/1 belongs to VLAN200, and establishes address mapping with MAC address

00-30-4f-f0-00-18.

Switch(config)#mac-address-table static address ,A8-F7-E0-f0-00-

18 vlan 200 interface

ethernet 1/0/1

Configure a static multicast MAC 01-00-5e-00-00-01, the egress is ehernet 1/0/1.

Switch(config)#mac-address-table static-multicast address 01-00-5e-00-00-01 vlan 1 interface

ethernet1/0/1

13.1.4 show mac-address-table

Command:

show mac-address-table [static | blackhole | multicast | aging-time <aging-time> | count]

[address <mac-addr>] [vlan <vlan-id>] [count] [interface <interface-name>]

Function:

Show the current MAC table.

Parameter:

static static entries; blackhole filter entries; aging-time <aging-time> address aging time; count

entry’s number, multicast multicast entries; <mac-addr> entry’s MAC address; <vlan-id> entry’s

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990
