Planet SGS-6341-24T4X User Manual

19-173
Command Mode:
Admin Mode
Example:
Switch#debug ip icmp
IP ICMP: sent, type 8, src 0.0.0.0, dst 20.1.1.1
Display Description
IP ICMP: sent Send ICMP packets
type 8
Type is 8（PING request）
src 0.0.0.0 Source IPv4 address
dst 20.1.1.1 Destination IPv4 address
19.2.4 debug ip packet
Command:
debug ip packet
no debug ip packet
Function:
Enable the IP packet debug function: the “no debug IP packet” command disables this debug
function.
Parameter:
None
Default:
IP packet debugging information is disabled by default.
Command mode:
Admin Mode
Usage Guide:
Displays statistics for IP packets received/sent, including source/destination address and bytes, etc.
Example:
Enabling IP packet debug.
Switch #debug ip packet
IP PACKET: sent, src 200.1.1.35, dst 224.0.0.9, size 312, proto 17, vrf 0
IP PACKET: rcvd, src 101.1.1.1, dst 224.0.0.9, size 312, proto 17, from Vlan200, vrf 0
19.2.5 debug ipv6 packet
Command:
debug ipv6 packet

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
