SGS-6341 Series Command Guide
1-61
function however encrypted passwords remain unchanged.
Example:
Encrypt system passwords
Switch(config)#service password-encryption
1.1.24 service terminal-length
Command:
service terminal-length <0-512>
no service terminal-length
Function:
Configure the columns of characters displayed in each screen on terminal (vty). The “no service terminal-length”
command cancels the screen shifting operation.
Parameter:
Columns of characters displayed on each screen of vty, ranging between 0-512.
Command mode:
Global Mode
Usage guide:
Configure the columns of characters displayed on each screen of the terminal. The columns of characters displayed
on each screen on the telent.ssh client and the Console will be following this configuration.
Example:
Set the number of vty threads to 20.
Switch(config)#service terminal-length 20
1.1.25 sysContact
Command:
sysContact <LINE>
no sysContact
Function:
Set the factory contact mode, the “no sysContact” command reset the switch to factory settings.
Parameter:
<LINE> is the prompt character string, range from 0 to 255 characters.
Command mode:
Global Mode
Default:
The factory settings.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
