Planet SGS-6341-24T4X User Manual

14-99
14.1.3 instance vlan
Command:
instance <instance-id> vlan <vlan-list>
no instance <instance-id> [vlan <vlan-list>]
Function:
In MSTP region mode, create the instance and set the mappings between VLANs and instances;
the command “no instance <instance-id> [vlan <vlan-list>]” removes the specified instance and
the specified mappings between the VLANs and instances.
Parameter:
Normally, <instance-id> sets the instance number. The valid range is from 0 to 64; in the command
“no instance <instance-id> [vlan <vlan-list>]”, <instance-id> sets the instance number. The valid
number is from 0 to 64. <vlan-list> sets consecutive or non-consecutive VLAN numbers. “-” refers
to consecutive numbers, and “;” refers to non-consecutive numbers.
Command mode:
MSTP Region Mode
Default:
Before creating any Instances, there is only the instance 0, and VLAN 1~4094 all belong to the
instance 0.
Usage Guide:
This command sets the mappings between VLANs and instances. Only if all the mapping
relationships and other attributes are same, the switches are considered in the same MSTP region.
Before setting any instances, all the VLANs belong to the instance 0. MSTP can support maximum
64 MSTIs (except for CISTs). CIST can be treated as MSTI 0. All the other instances are considered
as instance 1 to 64.
Example:
Map VLAN1-10 and VLAN 100-110 to Instance 1.
Switch(config)#spanning-tree mst configuration
Switch(Config-Mstp-Region)#instance 1 vlan 1-10;100-110
14.1.4 name
Command:
name <name>
no name
Function:
In MSTP region mode, set MSTP region name; the “no name” command restores the default

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
