Planet SGS-6341-24T4X User Manual

31-117
31.8 match ipv6 address
Command:
match ipv6 address <ipv6-acl-name | prefix-list list-name>
no match ipv6 address [<ipv6-acl-name | prefix-list list-name>]
Function:
Configure the prefix for ipv6 routing. If the no form command is enaled, the configuration will be
removed.
Parameters:
address is the routing prefix to be matched. <ipv6-acl-name> is the name of ipv6 access list. Or
when the prefix-list is configured. list-name will be the list name to be matched.
Command Mode:
route map mode
Usage Guide:
When this command is enabled, the prefix-list in the routing table will be used for routing decision.
And if matched, the permit deny operation in the route map will be executed.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#match ipv6 address prefix-list mylist
31.9 match ipv6 next-hop
Command:
match ipv6 next-hop <ipv6-address>
no match ipv6 next-hop [<ipv6-address>]
Function:
Configure the next hop for ipv6 routing. The no form command will disable the configuration.
Parameters:
next-hop is the next station for routing. ipv6-address is the ipv6 address for the ip address of the
interface on the next station.
Command Mode:
route map mode
Usage Guide:
If this command is configured, packets will be delivered according to the next hop information in the
routing table. If matched, the permit or deny operation in the route map will be executed.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
