Planet SGS-6341-24T4X User Manual

26-30
26.1.18 ip dhcp ping packets
Command:
ip dhcp ping packets <request-num>
no ip dhcp ping packets
Function:
Set the max number of Ping request (Echo Request) message to be sent in Ping-detection of
conflict on DHCP server, whose default value is 2; the no operation of this command will restore the
default value.
Parameters:
<request-num> is the number of Ping request message to be sent in Ping-detection of conflict.
Default Settings:
No more than 2 Ping request messages will be sent by default.
Command Mode:
Global Configuration Mode.
Examples:
Set the max number of Ping request (Echo Request) message to be sent in Ping-detection of
conflict on DHCP server as 3.
Switch(config)#ip dhcp ping packets 3
Related Command:
ip dhcp conflict ping-detection enable, ip dhcp ping timeout
26.1.19 ip dhcp ping timeout
Command:
ip dhcp ping timeout <timeout-value>
no ip dhcp ping timeout
Function:
Set the timeout period (in ms) of waiting for a reply message (Echo Request) after each Ping
request message (Echo Request) in Ping-detection of conflict on DHCP server, whose default value
is 500ms. The no operation of this command will restore the default value.
Parameters:
<timeout-value> is the timeout period of waiting for a reply message after each Ping request
message in Ping-detection of conflict.
Default Settings:
The timeout period is 500ms by default.
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
