Planet SGS-6341-24T4X User Manual

26-29
<name>“command deletes the specified address pool.
Parameters:
<name> is the address pool name, up to 32 characters are allowed.
Command mode:
Global Mode
Usage Guide:
This command is used to configure a DHCP address pool under Global Mode and enter the DHCP
address configuration mode.
Example:
Defining an address pool named “1”.
Switch(config)#ip dhcp pool 1
Switch(dhcp-1-config)#
26.1.17 ip dhcp conflict ping-detection enable
Command:
ip dhcp conflict ping-detection enable
no ip dhcp conflict ping-detection enable
Function:
Enable Ping-detection of conflict on DHCP server; the no operation of this command will disable the
function.
Default Settings:
By default, Ping-detection of conflict is disabled.
Command Mode:
Global Configuration Mode.
Usage Guide:
To enable Ping-detection of conflict, one should enable the log of conflict addresses, when which is
disabled, so will the ping-detection of conflict. When a client is unable to receive Ping request
messages (when blocked by firewall, for example), this function will check local ARP according to
allocated IP: if a designated IP has a corresponding ARP, then an address conflict exists; otherwise,
allocate it to the client.
Examples:
Enable Ping-detection of conflict.
Switch(config)#ip dhcp conflict ping-detection enable
Related Command:
ip dhcp conflict logging, ip dhcp ping packets, ip dhcp ping timeout

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
