Planet SGS-6341-24T4X User Manual

13-93
for the port.
Total MAC Addresses
Current secure MAC address number for the port.
Configured MAC Addresses Current secure static MAC address number for the
port.
Lock Timer Whether locking timer (timer timeout) is enabled
for the port.
Mac-Learning function Whether the MAC address learning function is
enabled.
13.2.6 switchport port-security
Command:
switchport port security
no switchport port security
Function:
Enable MAC address binding function for the port; the “no switchport port-security” command
disables the MAC address binding function for the port.
Command mode:
Port Mode.
Default:
MAC address binding is not enabled by default.
Usage Guide:
The MAC address binding function and Port Aggregation functions are mutually exclusive.
Therefore, if MAC binding function for a port is to be enabled, the Port Aggregation functions must
be disabled, and the port enabling MAC address binding must not be a Trunk port.
Example:
Enable MAC address binding function for port 1and.
Switch(config)#interface Ethernet 1/0/1
Switch(Config-If-Ethernet1/0/1)# switchport port security

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
