Planet SGS-6341-24T4X User Manual

12-68
Command mode:
Port Mode.
Default:
access mode.
Usage Guide:
Configure the port as trunk, enable it to leave all VLANs and clear allow-list.
Example:
Switch(config-if-ethernet1/0/1)#switchport mode trunk allow-null
12.1.32 switchport trunk allowed vlan
Command:
switchport trunk allowed vlan {WORD | all | add WORD | except WORD | remove WORD}
no switchport trunk allowed vlan
Function:
Set trunk port to allow VLAN traffic; the “no switchport trunk allowed vlan” command restores the
default setting.
Parameter:
WORD: specified VIDs; keyword;
all: all VIDs, the range from 1 to 4094;
add: add assigned VIDs behind allow vlan;
except: all VID add to allow vlan except assigned VIDs;
remove: delete assigned allow vlan from allow vlan list.
Command mode:
Port Mode.
Default:
Trunk port allows all VLAN traffic by default.
Usage Guide:
The user can use this command to set the VLAN traffic allowed to passthrough the Trunk port; traffic
of VLANs not included are prohibited.
Example:
Set Trunk port to allow traffic of VLAN1, 3, 5-20.
Switch(config)#interface ethernet 1/0/5
Switch(Config-If-Ethernet1/0/5)#switchport mode trunk
Switch(Config-If-Ethernet1/0/5)#switchport trunk allowed vlan 1;3;5-20
Switch(Config-If-Ethernet1/0/5)#exit

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
