Planet SGS-6341-24T4X User Manual

14-107
Default:
The link type is auto by default, The MSTP detects the link type automatically.
Usage Guide:
When the port is full-duplex, MSTP sets the port link type as point-to-point; When the port is
half-duplex, MSTP sets the port link type as shared.
Example:
Force the port 1/0/7-8 as point-to-point type.
Switch(config)#interface ethernet 1/0/7-8
Switch(Config-Port-Range)#spanning-tree link-type p2p force-true
14.1.15 spanning-tree maxage
Command:
spanning-tree maxage <time>
no spanning-tree maxage
Function:
Set the max aging time for BPDU; the command “no spanning-tree maxage” restores the default
setting.
Parameter:
<time> is max aging time in seconds. The valid range is from 6 to 40.
Command mode:
Global Mode
Default:
The max age is 20 seconds by default.
Usage Guide:
The lifetime of BPDU is called max age time. The max age is co working with hello time and forward
delay. The parameters should meet the following conditions. Otherwise, the MSTP may work
incorrectly.
2 * (Bridge_Forward_Delay - 1.0 seconds) >= Bridge_Max_Age
Bridge_Max_Age >= 2 * (Bridge_Hello_Time + 1.0 seconds)
Example:
In global mode, set max age time to 25 seconds.
Switch(config)#spanning-tree maxage 25

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
