Planet SGS-6341-24T4X User Manual

13-95
13.2.9 switchport port-security mac-address
Command:
switchport port-security mac-address <mac-address>
no switchport port-security mac-address <mac-address>
Function:
Add a static secure MAC address; the “no switchport port-security mac-address” command
deletes a static secure MAC address.
Command mode:
Port Mode.
Parameters:
<mac-address> stands for the MAC address to be added or deleted.
Usage Guide:
The MAC address binding function must be enabled before static secure MAC address can be
added.
Example:
Adding MAC 00-30-4f-FE-2E-D3 to port1.
Switch(config)#interface Ethernet 1/0/1
Switch(Config-If-Ethernet1/1)#switchport port-security mac-address 00-30-4f-FE-2E-D3
13.2.10 switchport port-security maximum
Command:
switchport port-security maximum <value>
no switchport port-security maximum
Function:
Sets the maximum number of secure MAC addresses for a port; the “no switchport port-security
maximum” command restores the maximum secure address number of 1.
Command mode:
Port Mode.
Parameter:
< value> is the up limit for static secure MAC address, the valid range is 1 to 128.
Default:
The default maximum port secure MAC address number is 1.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
