13-89
VLAN number; <interface-name> entry’s interface name.
Command Mode:
Admin and Configuration Mode.
Default:
MAC address table is not displayed by default.
Usage Guide:
This command can display various classes of MAC address entries. Users can also use show
mac-address-table to display all the MAC address entries.
Example:
Display all the filter MAC address entries.
Switch#show mac-address-table blackhole
13.2 Commands for Mac Address Binding
configuration
13.2.1 clear port-security dynamic
Command:
clear port-security dynamic [address <mac-addr> | interface <interface-id>]
Function:
Clear the Dynamic MAC addresses of the specified port.
Command mode:
Admin Mode.
Parameter:
<mac-addr> stands MAC address; <interface-id> for specified port number.
Usage Guide:
The secure port must be locked before dynamic MAC clearing operation can be perform in specified
port. If no ports and MAC are specified, then all dynamic MAC in all locked secure ports will be
cleared; if only port but no MAC address is specified, then all MAC addresses in the specified port
will be cleared.
Example:
Delete all dynamic MAC in port1.
Switch#clear port-security dynamic interface Ethernet 1/0/1
