Displayed Information
Explanations
Group
Mutlicast group IP address
Interface
Interface affiliated with Mutlicast group
Flags
Group property flag
Uptime
Mutlicast group uptime
Group Mode Group mode, including INCLUDE and EXCLUDE.
Group V3 will be available, group V1 and group V2
are regards as EXCLUDE mode.
Exptime
Mutlicast group expire time
Last Reporter
Last reporter to the host of the Mutlicast group
Source Address
Source address of this group
V3 Exp
Source expire time
Fwd
If the data of the source is forwarded or not.
Flags
Source property flag
44.9.16 show ip igmp interface
Command:
show ip igmp interface {vlan <vlan_id>|<ifname>}
Function:
Display related IGMP information on interface.
Parameter:
<ifname> is interface name, namely displaying IGMP information of specified interface.
Default:
Do not display
Command Mode:
Admin Mode
Example:
Display interface vlan1 IGMP message on Ethernet.
Switch (config)#show ip igmp interface Vlan1
Interface Vlan1(2005)
Index 2005
Internet address is 10.1.1.2
IGMP querier
IGMP current version is V3, 2 group(s) joined
IGMP query interval is 125 seconds
IGMP querier timeout is 255 seconds

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
