Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
3-114
received DP messages with DR messages.
The no operation of this command will restore the keepalive interval in the cluster back to its default value.
Example:
Set the keepalive interval in the cluster to 10 seconds.
Switch(config)#cluster keepalive interval 10
3.6 cluster keepalive loss-count
Command:
cluster keepalive loss-count<loss-count>
no cluster keepalive loss-count
Function:
Configure the max number of lost keepalive messages in a cluster that can be tolerated.
Parameters:
loss-count: the tolerable max number of lost messages, ranging from 1 to 10.
Default:
The default value is 3.
Command Mode:
Global Configuration Mode
Usage Guide:
After executing this command on a commander switch, the value of the parameter will be distributed to all member
switches via the TCP connections between the commander and members.
After executing it on a non commander switch, the configuration value will be saved but not used until the switch
becomes a commander. Before that, its loss-count value is the one distributed by its commander.
commander calculates the loss-count after sending each DP message by adding 1 to the loss-count of each switch
and clearing that of a switch after receiving a DR message from the latter. When a loss-count reaches the configured
value (3 by default) without receiving any DR message, the commander will delete the switch from its candidate chain
list.
If the time that a member fails to receive DP messages from the commander reaches loss-count, it will change its
status to candidate.
The no operation of this command will restore the tolerable max number of lost keepalive messages in the cluster
back to its default value: 3.
Example:
Set the tolerable max number of lost keepalive messages in the cluster to 5.
Switch(config)#cluster keepalive loss-count 5

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
