Planet SGS-6341-24T4X User Manual

34-178
route-map<word> is the pointer to the introduced routing map.
Default:
Not redistributed by default.
Command Mode:
RIPng Configuration Mode.
Example:
To redistribute OSPFv3 ABC routing ro RIPng.
Switch(config)#router ipv6 rip
Switch (config-router)#redistribute ospf abc
34.17 route
Command:
route <ipv6-address>
no route <ipv6-address>
Function:
This command configures a static RIPng route. The “no route <ipv6-address>“ command deletes
this route.
Parameter:
Specifies this destination IPv6 address prefix and its length show in colon hex notation.
Usage Guide:
The command adds a static RIPng route, and is mainly used for debugging. Routes configured by
this command will not appear in kernel route table but in the RIPng route database, however it could
be located by using the show ipv6 rip command.
Command Mode:
Router mode
Example:
Switch#config terminal
Switch(config)#router ipv6 rip
Switch(config-router)#route 3ffe:1234:5678::1/64
34.18 router ipv6 rip
Command:
router ipv6 rip

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
