SGS-6341 Series Command Guide
1-51
Command Mode:
Admin Mode.
Default:
The factory original configuration only specifies the first booting IMG file, the nos.img file in the FLASH, without the
second one.
Example:
1. Set flash:/nos.img as the second booting IMG file used in the next booting of the system.
Switch#boot img flash:/nos.img backup
2. Set flash:/5.4.128.0_nos.img as the first booting IMG file used in the next booting of the system.
Switch#boot img flash:/5.4.128.0_nos.img primary
1.1.4 boot startup-config
Command:
boot startup-config { NULL | <file-url> }
Function:
Configure the CGF file used in the next booting of the main control boardcard.
Parameters:
The NULL keyword means to use the factory original configuration as the next booting configuration. Setting the he
CGF file used in the next booting as NULL equals to implementing “set default” and “write”. <file-url> is the full path
of CGF file used in the next booting.
1. The file path comprises of two parts: device prefix used as the root directory (flash:/) and the file name. No space
is allowed in each part or between two parts.
2. The suffix of all file names should be .cfg.
3. The length of the full file path should be no longer than 128 characters, while the file name no longer than 80
characters.
Command Mode:
Admin Mode.
Default Settings:
None.
Example:
1. Set flash:/ startup.cfg as the booting CFG file used in the next booting of the system.
Switch# boot startup-configflash:/ startup.cfg
2. Set flash:/ test-trunk.cfg as the booting CFG file used in the next booting of the system.
Switch#boot startup-config flash:/ test-trunk.cfg

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
