Planet SGS-6341-24T4X User Manual

11-42
11.27 show ethernet-oam events
Command:
show ethernet-oam events {local | remote} [interface {ethernet |} <IFNAME>]
Function:
Shows the statistic information of link events on specified or all ports with OAM enabled, including
general link events and severe link events.
Parameter:
local, show the detailed information of the local events;
remote, show the detailed information of the remote events;
<IFNAME>, the port that the statistic information of OAM link events needs to be shown, the statistic
information of OAM link events for all ports will be shown if this parameter is not specified.
Command Mode:
Admin mode
Example:
Show the statistic information of link events on Ethernet 1/0/1.
Switch#show ethernet-oam events local interface 1/0/1
ethernet 1/0/1 link-events：
OAM_local_errored-symbol-period-events:
------------------------------------------------------------------------------------------------------
event time stamp：3539 errored symbol window：1s
errored symbol low threshold：1 errored symbol high threshold：none
errored symbol：1200120 errored running total：2302512542
event running total：232
OAM_local_errored-frame-period-events:
------------------------------------------------------------------------------------------------------
event time stamp：3539 errored frame window：10s
errored frame low threshold：1 errored frame high threshold：none
errored frame：1200120 errored running total：2302512542
event running total：52
OAM_local_errored-frame-events:
------------------------------------------------------------------------------------------------------
event time stamp：3539 errored frame window：1s
errored frame low threshold：1 errored frame high threshold：none
errored frame：1200120 errored running total：2302512542

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
