Usage Guide:
If the specified port group does not exist, then print a error message. All ports in a port group must
be added in the same mode, i.e., all ports use the mode used by the first port added. Adding a port
in “on” mode is a “forced” action, which means the local end switch port aggregation does not rely
on the information of the other end, port aggregation will succeed as long as all ports have
consistent VLAN information. Adding a port in “active” or “passive” mode enables LACP. Ports of at
least one end must be added in “active” mode, if ports of both ends are added in “passive” mode,
the ports will never aggregate.
Example:
Under the Port Mode of Ethernet1/0/1, add current port to “port-group 1” in “active” mode.
Switch(Config-If-Ethernet1/0/1)#port-group 1 mode active
9.9 show port-group
Command:
show port-group [<port-group-number>] {brief | detail |}
Function:
Display the specified group number or the configuration information of all port-channel which
have been configured.
Parameters:
<port-group-number> is the group number of port channel to be displayed, from 1 to 128;
brief displays summary information;
detail displays detailed information.
Command mode:
All Configuration Mode.
Usage Guide:
If the user does not input port-group-number, that means the information of all the existent
port-group are showed; if the port channel corresponds to port-group-number parameter and is not
exist, then print a error message, otherwise display the current port-channel information of the
specified group number.
Example:
1. Display the summary information of port-group 1.
Switch# show port-group brief
ID: port group number; Mode: port group mode such as on active or passive;
Ports: different types of port number of a port group,
the first is selected ports number, the second is standby ports number, and

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
