Planet SGS-6341-24T4X User Manual

12-74
12.2 Commands for Dynamic VLAN Configuration
12.2.1 dynamic-vlan mac-vlan prefer
Command:
dynamic-vlan mac-vlan prefer
Function:
Set the MAC-based VLAN preferred.
Command Mode:
Global Mode.
Default:
MAC-based VLAN is preferred by default.
Usage Guide:
Configure the preference of dynamic-vlan on switch. The default priority sequence is MAC-based
VLAN、IP-subnet-based VLAN、Protocol-based VLAN, namely the preferred order when several
dynamic VLAN is available. After the IP-subnet-based VLAN is set to be preferred and the user wish
to restore to preferring the MAC-based VLAN, please use this command.
Example:
Set the MAC-based VLAN preferred.
Switch#config
Switch(config)#dynamic-vlan mac-vlan prefer
12.2.2 dynamic-vlan subnet-vlan prefer
Command:
dynamic-vlan subnet-vlan prefer
Function:
Set the IP-subnet-based VLAN preferred.
Command Mode:
Global Mode.
Default:
MAC-based VLAN is preferred by default.
Usage Guide:
Configure the preference of dynamic-vlan on switch. The default priority sequence is MAC-based
VLAN、IP-subnet-based VLAN、Protocol-based VLAN, namely the preferred order when several

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
