SGS-6341 Series Command Guide
3-121
Switch#show cluster members
Member From : User config(U); Auto member (A)
ID From Status Mac Hostname Description Internal IP
--- - ----------- ----------------- ------------ ------------ ---------------
xxx x xxxxxxxxxx12 xx-xx-xx-xx-xx-xx xxxxxxxxxx12 xxxxxxxxxx12 xxx.xxx.xxx.xxx
1 U Inactive 00-01-02-03-04-05 MIS_zebra SGS-6341-24T4X 10.254.254.2
2 A Active 00-01-02-03-04-05 MIS_bison SGS-6341-24T4X 10.254.254.3
3 U Active 00-01-02-03-04-05 SRD_jaguar SGS-6341-24T4X 10.254.254.4
4 A Inactive 00-01-02-03-04-05 HRD_puma SGS-6341-24T4X 10.254.254.5
----
Switch#show cluster members id 1
Cluster Members:
ID: 1
Member status: Inactive member (user_config)
IP Address: 10.254.254.2
MAC Address: 00-01-02-03-04-06
Description: SGS-6341-24T4X
Hostname: DSW102
3.16 show cluster candidates
Command:
show cluster candidates [nodes-sn <candidate-sn-list> | mac-address <mac-addr>]
Function:
Display the statistic information of the candidate member switches on the command switch
Parameter:
candidate-sn-listcandidate switch sn, ranging from 1 to 256. More than one switch can be specified.
mac-address mac address of the candidate switch
Default:
No parameters means to display information of all member switches.
Command Mode:
Admin and Configuration Mode.
Usage Guide:
Executing this command on the switch will display the information of the candidate member switches.
Example:
Display configuration information of all cluster candidate switches.
Switch#show cluster candidates
Cluster Candidates:

Table of Contents

Other manuals for Planet SGS-6341-24T4X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet SGS-6341-24T4X and is the answer not in the manual?

Planet SGS-6341-24T4X Specifications

General IconGeneral
Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Form factor1U
CertificationFCC Part 15 Class A, CE
Product colorBlack
Console portRJ-45
SFP+ module slots quantity4
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity24
Routing entries128
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresStacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Flash memory16 MB
Internal memory512 MB
Processor frequency400 MHz
AuthenticationMAC-based authentication, Port-based authentication
Security algorithmsSNMPv3, SSH, SSL/TLS
Throughput95.24 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply included-
Power consumption (max)19.9 W
Heat dissipation67.91 BTU/h
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width440 mm
Height43.6 mm
Weight3170 g
