Planet SGS-6341-24T4X User Manual

44-6
Chapter 44 IPv4 Multicast Protocol
44.1 Public Commands for Multicast
44.1.1 show ip mroute
Command:
show ip mroute [<GroupAddr> [<SourceAddr>]]
Function:
show IPv4 software multicast route table.
Parameter:
GroupAddr: show the multicast entries relative to this Group address.
SourceAddr: show the multicast route entries relative to this source address.
Command Mode:
Admin mode and global mode
Example:
show all entries of multicast route table.
Switch(config)#show ip mroute
Name: Loopback, Index: 2002, State:49
Name: null0, Index: 2003, State:49
Name: sit0, Index: 2004, State:80
Name: Vlan1, Index: 2005, State:1043
Name: Vlan2, Index: 2006, State:1002
Name: pimreg, Index: 2007, State:c1
The total matched ipmr active mfc entries is 1, unresolved ipmr entries is 0
Group Origin Iif Wrong Oif:TTL
225.1.1.1 192.168.1.136 vlan1 0 2006:1
Displayed information
Explanation
Name
the name of interface
Index
the index number of interface
State
the state of interface
The total matched ipmr active mfc entries The total matched active IP multicast route mfc
（multicast forwarding cache） entries
unresolved ipmr entries
unresolved ip multicast route entries
Group
the destination address of the entries
Origin
the source address of the entries

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
