Planet SGS-6341-24T4X User Manual

44-7
Iif
ingress interface of the entries
Wrong
packets received from the wrong interface
Oif
egress interface of the entries
TTL
the value of TTL
44.2 Commands for PIM-DM
44.2.1 debug pim timer sat
Command:
debug pim timer sat
no debug pim timer sat
Function:
Enable debug switch of PIM-DM source activity timer information in detail; the “no debug pim timer
sat” command disenables the debug switch.
Default:
Disabled.
Command Mode:
Admin Mode.
Usage Guide:
Enable the switch, and display source activity timer information in detail.
Example:
Switch # debug ip pim timer sat
Remark:
Other debug switches in PIM-DM are common in PIM-SM, including debug pim event, debug pim
packet, debug pim nexthop, debug pim nsm, debug pim mfc, debug pim timer, debug pim state,
refer to PIM-SM handbook.
44.2.2 debug pim timer srt
Command:
debug pim timer srt
no debug pim timer srt
Function:
Enable debug switch of PIM-DM state-refresh timer information in detail; the “no debug pim timer
srt” command disenables the debug switch.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
