Planet SGS-6341-24T4X User Manual

44-8
Default:
Disabled.
Command Mode:
Admin Mode.
Usage Guide:
Enable the switch, and display PIM-DM state-refresh timer information in detail.
Example:
Switch #debug ip pim timer srt
Remark:
Other debug switches in PIM-DM are common in PIM-SM, including debug pim event, debug pim
packet, debug pim nexthop, debug pim nsm, debug pim mfc, debug pim timer, debug pim state,
refer to PIM-SM manual section.
44.2.3 ip mroute
Command:
ip mroute <A.B.C.D> <A.B.C.D> <ifname> <.ifname>
no ip mroute <A.B.C.D> <A.B.C.D> [<ifname> <.ifname>]
Function:
To configure static multicast entry. The no command will delete some static multicast entries or
some egress interfaces.
Parameter:
<A.B.C.D> <A.B.C.D> are the source address and group address of multicast.
<ifname> <.ifname>, the first one is ingress interface, follow is egress interface.
Default:
To delete this static multicast entry, if the command isn’t included interface parameter.
Command Mode:
Global Mode.
Usage Guide:
The <ifname> should be valid VLAN interfaces. The multicast data flow will not be forwarded
unless PIM is configured on the egress interface and the interface is UP. If the state of the interface
is not UP, or PIM is not configured, or RPF is not valid, the multicast data flow will not be fordwarded.
To removed the specified multicast routing entry. If all the egress interfaces are specified, or no
interfaces are specified, the specified multicast routing entry will be removed. Otherwise the
multicast routing entry for the specified interface will be removed.
Example:
Switch(config)#ip mroute 10.1.1.1 225.1.1.1 v10 v20 v30

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
