Planet SGS-6341-24T4X User Manual

33-163
Routing for Networks:
Vlan1
Vlan2
The segment running RIP is the
Vlan 1 and Vlan 2
Routing Information Sources:
Gateway Distance Last Update Bad Packets Bad Routes
20.1.1.1 120 00:00:31 0 0
Routing information sources
The badpacketand bad routes from
the gateway 20.1.1.1 are all 0. 31
seconds have passed since the
last route update. The manage
distance is 120
Distance: (default is 120) Default manage distance is 120
33.37 show ip rip
Command:
show ip rip
Function:
Show the routes in the RIP route data base.
Command Mode:
Admin mode
Example:
show ip rip
Codes: R - RIP, K - Kernel, C - Connected, S - Static, O - OSPF, I - IS-IS,
B – BGP
Network Next Hop Metric From If Time
R 12.1.1.0/24 20.1.1.1 2 20.1.1.1 Vlan1 02:51
R 20.1.1.0/24 1 Vlan1
Amongst R stands for RIP route, namely a RIP route with the destination network address
12.1.1.0, the network prefix length as 24, next-
hop address at 20.1.1.1. It is learnt from the
Ethernet port E1/8 with a metric value of 2, and still has 2 minutes 51 seconds before time out.
33.38 show ip rip database
Command:
show ip rip database
Function:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
