Planet SGS-6341-24T4X User Manual

34-181
Example:
Switch#show ipv6 rip redistribute
34.22 show ipv6 protocols rip
Command:
show ipv6 protocols rip
Function:
Show the RIPng process parameters and statistic messages.
Command Mode:
Admin mode
Example:
Switch(config)#show ipv6 protocols rip
Routing Protocol is "RIPng"
Sending updates every 30 seconds with +/-50%, next due in 1 second
Timeout after 180 seconds, garbage collect after 120 seconds
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Ethernet1/10 filtered by dclist
Default redistribute metric is 1
Redistributing: static
Interface
Vlan10
Vlan2
Routing for Networks:
Displayed information
Explanations
Sending updates every 30 seconds with +/-50%, next due in 1
seconds
Sending updates every 30 seconds
Timeout after 180 seconds, garbage collect after 120 seconds
The route timeout time is 180
seconds, the garbage collect time
is 120 seconds
Outgoing update filter list for all interface is not set Outgoing update filter list for all
interface is not set
Incoming update filter list for all interface is not set
Incoming update filter list for all

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
