Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-56
Switch#
1.1.14 help
Command:
help
Function:
Output brief description of the command interpreter help system.
Command mode:
All configuration modes.
Usage Guide:
An instant online help provided by the switch. Help command displays information about the whole help system,
including complete help and partial help. The user can type in ? any time to get online help.
Example:
switch(config)#help
PLANETOS CLI provides advanced help feature. When you need help, anytime at the command line please press
'?'. If nothing matches, the help list will be empty and you must backup until entering a '?' shows the available options.
Two styles of help are provided:
1. Full help is available when you are ready to enter acommand argument (e.g. 'show ?') and describes each
possible argument.
2. Partial help is provided when an abbreviated argument is entered and you want to know what arguments match
the input (e.g. 'show ve?'.)
1.1.15 hostname
Command:
hostname <hostname>
no hostname
Function:
Set the prompt in the switch command line interface. The no operation cancels the configuration.
Parameter:
<hostname> is the string for the prompt, up to 30 characters are allowed.
Command mode:
Global Mode
Default:
The default prompt is relatived with the switch.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
