SGS-6341 Series Command Guide

4-133

Usage Guide:

All ports in the switch belong to a same broadcast domain if no VLAN has been set. The switch will send the above

mentioned three traffics to all ports in the broadcast domain, which may result in broadcast storm and so may greatly

degrade the switch performance. Enabling Broadcast Storm Control can better protect the switch from broadcast

storm. Note the difference of this command in 10Gb ports and other ports. If the allowed traffic is set to 3, this means

allow 3,120 packets per second and discard the rest for 10Gb ports. However, the same setting for non-10Gb ports

means to allow 3 broadcast packets per second and discard the rest.

Example:

Setting ports 8-10 (1000Mbps) allow 3 broadcast packets per second.

Switch(config)#interface ethernet 1/0/8-10

Switch(Config-Port-Range)#rate-suppression broadcast 3

4.1.13 rate-violation

Command:

rate-violation <200-2000000> [recovery <0-86400>|]

no rate-violation

Function:

Set the max packet reception rate of a port. If the rate of the received packet violates the packet reception rate, shut

down this port and configure the recovery time, the default is 300s. The no command will disable the rate-violation

function of a port.

The rate-violation means the port received all packets rate (the number of the received packets per second), do not

distinguish the packet type.

Parameters:

<200-2000000> the max packet reception rate of a port, the unit is packets/s.

<0-86400>: The interval of recovery after shutdown, the unit is s.

recovery: After a period of time the port can recover shutdown to up again. <0-86400> is the timeout of recovery. For

example, if the shutdown of a port happens after the packet reception rate exceeding the limit, the port will be up

again when the user-defined timeout expires. The default timeout is 300s, while 0 means the recovery will never

happen.

Command Mode:

Interface Mode

Default:

There is no control operation for rate-violation.

Usage Guide:

This command is mainly used to detect the abnormal port flow. For example, when there are a large number of

broadcast messages caused by a loopback, which affect the processing of other tasks, the port will be shut down to

ensure the normal processing of the switch.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990
