14.1.8 spanning-tree
Command:
spanning-tree
no spanning-tree
Function:
Enable MSTP in global mode and in Port Mode; The command “no spanning-tree” is to disable
MSTP.
Command mode:
Global Mode and Port Mode
Default:
MSTP is not enabled by default.
Usage Guide:
If the MSTP is enabled in global mode, the MSTP is enabled in all the ports except for the ports
which are set to disable the MSTP explicitly.
Example:
Enable the MSTP in global mode, and disable the MSTP in the interface1/0/2.
Switch(config)#spanning-tree
Switch(config)#interface ethernet 1/0/2
Switch(Config-If-Ethernet1/0/2)#no spanning-tree
14.1.9 spanning-tree cost
Command:
spanning-tree cost <cost>
no spanning-tree cost
Function:
Sets path cost of the current port; the command “no spanning-tree cost” restores the default
setting.
Command mode:
Port Mode
Parameter:
<cost> sets path cost. The valid range is from 1 to 200,000,000.
Default:
By default, the port cost is relevant to the port bandwidth.
Port Type
Default Path Cost
Suggested Range
10Mbps
2000000
2000000~20000000

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
