Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-128
switch will automatically start HOL control (discarding some packets in the COS queue that may result in HOL) to
prevent drastic degradation of network performance.
Note:
Port flow control function is not recommended unless the users need a slow speed, low performance network with
low packet loss. Flow control will not work between different cards in the switch. When enable the port flow control
function, speed and duplex mode of both ends should be the same.
Example:
Enabling the flow control function in ports1/0/1-8.
Switch(config)#interface ethernet 1/0/1-8
Switch(Config-Port-Range)#flow control
4.1.5 interface ethernet
Command:
interface ethernet <interface-list>
Function:
Enters Ethernet Port Mode from Global Mode.
Parameters:
<interface-list> stands for port number.
Command mode:
Global Mode
Usage Guide:
Run the exit command to exit the Ethernet Port Mode to Global Mode.
Example:
Entering the Ethernet Port Mode for ports1/0/1, 1/0/4-5, 1/0/8.
Switch(config)#interface ethernet 1/0/1, 1/0/4-5, 1/0/8
Switch(Config-Port-Range)#
4.1.6 loopback
Command:
loopback
no loopback
Function:
Enables the loopback test function in an Ethernet port; the “no loopback” command disables the loopback test on
an Ethernet port.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
