SGS-6341 Series Command Guide
1-85
number of requested variable
Number of variables requested by NMS.
number of altered variables
Number of variables set by NMS.
get-request PDUs
Number of packets received by “get” requests.
get-next PDUs
Number of packets received by “getnext”
requests.
set-request PDUs
Number of packets received by “set” requests.
snmp packets output
Total number of SNMP packet outputs.
too big errors
Number of “Too_ big” error SNMP packets.
maximum packet size
Maximum length of SNMP packets.
no such name errors Number of packets requesting for non-existent
MIB objects.
bad values errors
Number of “Bad_values” error SNMP packets.
general errors
Number of “General_errors” error SNMP packets.
response PDUs
Number of response packets sent.
trap PDUs
Number of Trap packets sent.
1.4.6 show snmp engineid
Command:
show snmp engineid
Function:
Display the engine ID commands.
Command Mode:
Admin and Configuration Mode.
Example:
Switch#show snmp engineid
SNMP engineID:3138633303f1276c Engine Boots is:1
Displayed Information
SNMP engineID
Engine Boots
