Page #593 background imageLoading...
Page #593 background image
36-232
Chapter 36 Commands for OSPFv3
36.1 area default cost
Command:
area <id> default-cost <cost>
no area <id> default-cost
Function:
Configure the cost of sending to the default summary route in stub or NSSA area; the “no area <id>
default-cost” command restores the default value.
Parameter:
<id> is the area number which could be shown as digits 04294967295, or as an IP address;
<cost> ranges between <0-16777215>
Default:
Default OSPFv3 cost is 1.
Command Mode:
OSPFv3 protocol mode
Usage Guide:
The command is only adaptive to the ABR router connected to the stub area.
Example:
Set the default-cost of area 1 to 10
Switch(config-router)#area 1 default-cost 10
36.2 area range
Command:
area <id> range <ipv6address> [advertise| not-advertise|]
no area <id> range <ipv6address>
Function:
Aggregate OSPF route on the area border. The “no area <id> range <address>cancels this
function.
Parameter:
<id> is the area number which could be digits ranging between 04294967295, and also as an IP
address.
<ipv6address>=<X:X::X:X/M>,Specifies the area ipv6 network prefix and its length
