Planet SGS-6341-24T4X User Manual

14-119
14.2 Commands for Monitor and Debug
14.2.1 debug spanning-tree
Command:
debug spanning-tree
no debug spanning-tree
Function:
Enable the MSTP debugging information; the command “no debug spanning-tree” disables the
MSTP debugging information.
Command mode:
Admin Mode
Usage Guide:
This command is the general switch for all the MSTP debugging. Users should enable the detailed
debugging information, then they can use this command to display the relevant debugging
information. In general, this command is used by skilled technicians.
Example:
Enable to receive the debugging information of BPDU messages on the port1/0/1.
Switch#debug spanning-tree
Switch#debug spanning-tree bpdu rx interface e1/0/1
14.2.2 show mst-pending
Command:
show mst-pending
Function:
In the MSTP region mode, display the configuration of the current MSTP region.
Command mode:
Admin Mode
Usage Guide:
In the MSTP region mode, display the configuration of the current MSTP region such as MSTP
name, revision, VLAN and instance mapping.
Note: Before quitting the MSTP region mode, the displayed parameters may not be effective.
Example:
Display the configuration of the current MSTP region.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
