Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-68
The user can select the language according to their preference.
1.1.38 write
Command:
write
Function:
Save the currently configured parameters to the Flash memory.
Command mode:
Admin Mode.
Usage Guide:
After a set of configuration with desired functions, the setting should be saved to the Flash memory, so that the
system can revert to the saved configuration automatically in the case of accidentally powered off or power failure.
This is the equivalent to the copy running-config startup-config command.
1.2 Commands for Telnet
1.2.1 authentication ip access-class
Command:
authentication ip access-class {<num-std>|<name>}
no authentication ip access-class
Function:
Binding standard IP ACL protocol to login with Telnet/SSH/Web; the no form command will cancel the binding ACL.
Parameters:
<num-std> is the access-class number for standard numeric ACL, ranging between 1-99;
<name> is the access-class name for standard ACL, the character string length is ranging between 1-32.
Default:
The binding ACL to Telnet/SSH/Web function is closed by default.
Command Mode:
Global Mode.
Example:
Binding standard IP ACL protocol to access-class 1.
Switch(config)#authentication ip access-class 1 in

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
