Page #554 background imageLoading...
Page #554 background image
35-193
OSPF protocol mode
Example:
Switch#config terminal
Switch(config)#router ospf 100
Switch(config-router)#compatible rfc1583
35.10 clear ip ospf process
Command:
clear ip ospf [<process-id>] process
Function:
Use this command to clear and restart OSPF routing processes. One certain OSPF process will be
cleared by specifying the process ID, or else all OSPF processes will be cleared.
Default:
No default configuration.
Command Mode:
Admin mode
Example:
Switch#clear ip ospf process
35.11 debug ospf events
Command:
debug ospf events [abr|asbr|lsa|nssa|os|router|vlink]
no debug ospf events [abr|asbr|lsa|nssa|os|router|vlink]
Function:
Open debugging switches showing various OSPF events messages; the no debug ospf events
[abr|asbr|lsa|nssa|os|router|vlink]” command closes the debugging switch.
Default:
Closed
Command Mode:
Admin and global mode
Example:
Switch#debug ospf events router
