Planet SGS-6341-24T4X User Manual

36-252
Displayed information’s
Explanations
Link-LSA (Interface Vlan1)
Link LSA messages of interface Vlan1
Router-LSA (Area 0.0.0.0)
Router LSA messages in Area 0
Network-LSA (Area 0.0.0.0)
Network LSA in Area 0
Intra-Area-Prefix-LSA (Area 0.0.0.0)
Intra-domain Prefix LSA in Area 0
36.32 show ipv6 ospf interface
Command:
show ipv6 ospf interface <ifname>|vlan <vlan-id>
Function:
Display the OSPF interface messages.
Parameter:
<ifname> is the name of the interface.
Default:
Not displayed
Command Mode:
All modes
Example:
Switch#show ipv6 ospf interface
Loopback is up, line protocol is up
OSPFv3 not enabled on this interface
Vlan1 is up, line protocol is up
Interface ID 2003
IPv6 Prefixes
fe80::203:fff:fe01:257c/64 (Link-Local Address)
2001:1:1::1/64
OSPFv3 Process (*null*), Area 0.0.0.0, Instance ID 0
Router ID 192.168.2.2, Network Type BROADCAST, Cost: 10
Transmit Delay is 1 sec, State DR, Priority 1
Designated Router (ID) 192.168.2.2
Interface Address fe80::203:fff:fe01:257c
Backup Designated Router (ID) 192.168.2.3

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
