Planet SGS-6341-24T4X User Manual

29-72
Chapter 29 Commands for DHCPv6
option37, 38
29.1 Commands for DHCPv6 option37, 38
29.1.1 address range
Command:
address range <start-ip> <end-ip>
no address range <start-ip> <end-ip>
Function:
This command is used to set address range for a DHCPv6 class in DHCPv6 address pool
configuration mode, the no command is used to remove the address range. The prefix/plen form is
not supported.
Parameters:
start-ip, defines the start address of the address pool
end-ip, defines the end address of the address pool
Command Mode:
Admin Mode.
Usage Guide:
It is necessary to check the address range assigned to class in order to make sure that it doesn’t
exceed the address range of relevant address pool. A class is assigned a single address range and
the address range assigned to different class in the same address pool can overlap. If you do not
use this command to assign address range for a DHCPv6 class, then the range for it will be the
whole subnet of the address pool by default.
Example:
Associate a DHCPv6 class named CLASS1 to dhcpv6 pool 1 and assign the address range from
2001:da8:100:1::2 to 2001:da8:100:1::30 for CLASS1.
Switch(Config)#ipv6 dhcp pool 1
Switch(dhcp-1-config)#class CLASS1
Switch(dhcp-1-class-CLASS1-config)#address range 2001:da8:100:1::2 2001:da8:100:1::30
29.1.2 class

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
