SGS-6341 Series Command Guide
1-90
Command mode:
Global mode
Default:
SNMP proxy server function is disabled by system default.
Usage guide:
To perform configuration management on the switch with network manage software, the SNMP proxy server function
has to be enabled with this command.
Example:
Enable the SNMP proxy server function on the switch.
Switch(config)#snmp-server enable
1.4.14 snmp-server enable traps
Command:
snmp-server enable traps
no snmp-server enable traps
Function:
Enable the switch to send Trap message; the “no snmp-server enable traps” command disables the switch to send
Trap message.
Command mode:
Global Mode
Default:
Forbid to send Trap message.
Usage Guide:
When Trap message is enabled, if Down/Up in device ports or of system occurs, the device will send Trap messages
to NMS that receives Trap messages.
Example:
Enable to send Trap messages.
Switch(config)#snmp-server enable traps
Disable to send Trap messages.
Switch(config)#no snmp-server enable traps

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
