1.1.30 show cpu usage
Command:
show cpu usage [<slotno>]
Function:
Show CPU usage rate.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Check the current usage of CPU resource by show cpu usage command. Only the chassis switch uses slotno
parameter which is used to show the CPU usage rate of the card on specified slot, if there is no parameter, the
default is current card.
Example:
Show the current usage rate of CPU.
Switch#show cpu usage
Last 5 second CPU IDLE: 87%
Last 30 second CPU IDLE: 89%
Last 5 minute CPU IDLE: 89%
From running CPU IDLE: 89%
Command related:
clock set
1.1.31 show memory usage
Command:
show memory usage [<slotno>]
Function:
Show memory usage rate.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Check the current usage of memory resource by show memory usage command. Only the chassis switch uses
slotno parameter which is used to show the memory usage rate of card on the specified slot, if there is no parameter,
the default is current card.
Example:
Show the current usage rate of the memory.
Switch#show memory usage
The memory total 128 MB, free 58914872 bytes, usage is 56.10%

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
