SGS-6341 Series Command Guide
7-148
Chapter 7 Commands for ULDP
7.1 debug uldp
Command:
debug uldp (hello | probe | echo | unidir | all) [receive | send] interface [ethernet] IFNAME
no debug uldp (hello | probe | echo | unidir | all) [receive | send] interface [ethernet] IFNAME
Function:
Enable the debugging for receiving and sending the specified packets or all ULDP packets on port. After enable the
debugging, show the information of the received and sent packets in terminal. The no command disables the
debugging.
Parameters:
hello: packet's type is hello, it's announcement packet, including common announcement packet, RSY and Flush
packet
probe: packet's type is probe, it's detection packet
echo: packet's type is echo, it means response of detection packet
unidir: packet's type is unidir, it's announcement packet that discover the single link
all: All ULDP packets
Admin Configuration Mode.
Default:
Disabled
Example:
With this command, user can check probe packets received by port 1/0/2.
Switch# debug uldp probe receive interface ethernet 1/0/2
7.2 debug uldp error
Command:
debug uldp error
no debug uldp error
Function:
Enable the error message debug function, the no form command disable the function.
Command Mode:
Admin Mode.
Default:
Disabled.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
