Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-83
Usage Guide:
When user encounters problems in applying SNMP, the SNMP debugging is available to locate the problem causes.
Example:
Switch#debug snmp kernel
1.4.3 rmon enable
Command:
rmon enable
no rmon enable
Function:
Enable RMON; the “no rmon enable” command disables RMON.
Command mode:
Global Mode
Default:
RMON is disabled by default.
Example:
Enable RMON.
Switch(config)#rmon enable
Disable RMON.
Switch(config)#no rmon enable
1.4.4 show private-mib oid
Command:
show private-mib oid
Function:
Show the original oid of the private mib.
Command mode:
Admin and configuration mode.
Usage Guide:
Check the beginning oid of the private mib by show private-mib oid command.
Example:
Show the original oid of the private mib.
Switch#show private-mib oid
Private MIB OID:1.3.6.1.4.1.6339

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
