Planet SGS-6341-24T4X User Manual

13-97
13.2.12 switchport port-security violation
Command:
switchport port-security violation {protect | shutdown} [recovery <30-3600>]
no switchport port-security violation
Function:
Configure the port violation mode. The no restores the violation mode to protect.
Command Mode:
Port mode.
Parameter:
protect refers to protect mode
shutdown refers to shutdown mode
recovery: configure the border port can be recovered automatically after implement
shutdown violation operation
<30-3600>: the recovery time, do not recover it by default
Default:
The port violation mode is protect by default.
Usage Guide:
The port violation mode configuration is only available after the MAC address binding function is
enabled. when the port secure MAC address exceeds the security MAC limit, if the violation mode is
protect, the port only disable the dynamic MAC address learning function; while the port will be shut
if at shutdown mode. Users can manually open the port with no shutdown command.
Example
：
Set the violation mode of port 1 to shutdown.
Switch(config)#interface Ethernet 1/0/1
Switch(Config-If-Ethernet1/0/1)# switchport port-security violation shutdown recovery 60

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
