Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-99
Switch#copy tftp://10.1.1.1/nos.img nos.img
(3) Save images in the FLASH to the TFTP server of 2004:1:2:3::6
Switch#copy nos.img tftp:// 2004:1:2:3::6/ nos.img
(4) Obtain system file nos.img from the TFTP server 2004:1:2:3::6
Switch#copy tftp:// 2004:1:2:3::6/nos.img nos.img
(5) Save the running configuration files
Switch#copy running-config startup-config
Relevant Command:
Write
1.5.3 ftp-dir
Command:
ftp-dir <ftp-server-url>
Function:
Browse the file list on the FTP server.
Parameter:
The form of <ftp-server-url> is： ftp://<username>:<password>@{ <ipv4address> | <ipv6address> }, amongst
<username> is the FTP user name, <password> is the FTP user password, { <ipv4address> | <ipv6address> } is the
IPv4 or IPv6 address of the FTP server.
Command Mode:
Admin Mode
Example:
Browse the list of the files on the server with the FTP client, the username is “Switch”, the password is “superuser”
Switch#ftp-dir ftp://Switch:superuser @10.1.1.1.
1.5.4 ftp-server enable
Command:
ftp-server enable
no ftp-server enable
Function:
Start FTP server, the “no ftp-server enable” command shuts down FTP server and prevents FTP user from logging
in.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
