Page #522 background imageLoading...
Page #522 background image
33-161
Command Mode:
Keychain-key mode
Example:
The example below shows the send-lifetime configuration on the keychain named mychain for key
1.
Switch# config terminal
Switch(config)# key chain mychain
Switch(config-keychain)# key 1
Switch(config-keychain-key)# send-lifetime 03:03:01 Dec 3 2004 04:04:02 Oct 6 2006
Related Command:
key, key-string, key chain, accept-lifetime
33.35 show debugging rip
Command:
show debugging rip
Function:
Show RIP event debugging, RIP packet debugging and RIP nsm debugging status.
Command Mode:
Admin and configuration mode
Example:
Switch# show debugging rip
RIP debugging status:
RIP event debugging is on
RIP packet detail debugging is on
RIP NSM debugging is on
33.36 show ip protocols rip
Command:
show ip protocols rip
Function:
Show the RIP process parameter and statistics information.
Command Mode:
Admin and configuration mode
