Planet SGS-6341-24T4X User Manual

12-81
vlan-id is the VLAN ID with a valid range of 1~4094;all indicates all the subnets.
Command Mode:
Global Mode.
Default:
No IP subnet joined the VLAN by default.
Usage Guide:
This command is used for adding specified IP subnet to specified VLAN. When packet without
VLAN label and from the specified IP subnet enters through the switch port, it will be matched with
specified VLAN id and enters specified VLAN. These packets will always come to the same VLAN
no matter through which port did they enter. This command will not interfere with VLAN labeled data
packets.
Example:
Add the network equipment with IP subnet of 192.168.1.0/24 to VLAN 300.
SwitchA#config
SwitchA(config)#subnet-vlan ip-address 192.168.1.1 mask 255.255.255.0 vlan 300 priority 0
12.2.13 switchport mac-vlan enable
Command:
switchport mac-vlan enable
no switchport mac-vlan enable
Function:
Enable the MAC-based VLAN function on the port; the "no” form of this command will disable the
MAC-based VLAN function on the port.
Command Mode:
Port Mode.
Default:
The MAC-base VLAN function is enabled on the port by default.
Usage Guide:
After adding a MAC address to specified VLAN, the MAC-based VLAN function will be globally
enabled. This command can disable the MAC-based VLAN function on specified port to meet
special user applications.
Example:
Disable the MAC-based VLAN function on port1.
Switch#config
Switch(config)#interface ethernet 1/0/1
Switch(Config-If-Ethernet1/0/1)#no switchport mac-vlan enable

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
